9PX G2 10KVA 120V STEP-DOWN TRA 8 5-20R 2 L14-30R 50/60 HZ HW 3URM

Name: 9PX G2 10KVA 120V STEP-DOWN TRA 8 5-20R 2 L14-30R 50/60 HZ HW 3URM
Brand: EATON
SKU: SN0848
Price: 2788.68 USD
Availability: InStock

EATON

PCN#

SN0848

MFG#

9PXTFMR11G2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$2,788.68

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Estimated Shipment:

Product Highlights:

10000 VA
230 V AC Input
100 V, 120 V Output
3U

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 217 lbs.

Eaton 9PX G2 10kVA 120V Step-Down Transformer - 8 NEMA 5-20R and 2 L14-30R Outlets, 50/60 Hz, Hardwire Input, 3U Rack/Tower

Overview

208V to 120V Transformer Converts High-Voltage Input to Low-Voltage OutputThis 10kVA Step-Down Transformer converts your UPS system's 208V high-voltage input to 120V low-voltage output. It features eight NEMA 5-20R and two L14-30R outlets for connecting equipment. Resettable circuit breakers protect your 120V equipment against overload conditions. The 9PXTFMR11G2 works with Eaton's 9PX8KG2 and 9PX11KG2 9PX G2 UPS systems.Product TypeStep Down TransformerTechnical InformationPower Rating10000 VAInput Receptacle TypeHardwiredOutput Receptacle TypeNEMA 5-20RNEMA L14-30ROutput Receptacle Detail8 x NEMA 5-20R2 x NEMA L14-30RPower DescriptionInput Voltage230 V ACOutput Voltage100 V120 VPhysical CharacteristicsForm FactorTower/Rack MountableRack Height3UHeight5.1"Width17.3"Depth27.4"Environmental ConditionsMinimum Operating Temperature32°F (0°C)Maximum Operating Temperature104°F (40°C)MiscellaneousPackage Contents9PXTFMR11G2 Step Down TransformerHardwire Cable2 x Cable GlandsJoining Bracket And Hardware For Tower ConfigurationRack-Mounting HardwareOwner's ManualsCompatibility

Tech Specs

Versatile Installation OptionsYou can mount the 9PXTFMR11G2 in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit or adapt it for tower installation using the included joining bracket and hardware. Cable glands are included for hardwire input.Product TypeStep Down TransformerTechnical InformationPower Rating10000 VAInput Receptacle TypeHardwiredOutput Receptacle Type

NEMA 5-20R
NEMA L14-30R

Output Receptacle Detail

8 x NEMA 5-20R
2 x NEMA L14-30R

Power DescriptionInput Voltage230 V ACOutput Voltage

100 V
120 V

Physical CharacteristicsForm FactorTower/Rack MountableRack Height3UHeight5.1"Width17.3"Depth27.4"Environmental ConditionsMinimum Operating Temperature32°F (0°C)Maximum Operating Temperature104°F (40°C)MiscellaneousPackage Contents

9PXTFMR11G2 Step Down Transformer
Hardwire Cable
2 x Cable Glands
Joining Bracket And Hardware For Tower Configuration
Rack-Mounting Hardware
Owner's Manuals

Compatibility Eaton's 9PX G2 UPS Systems

9PX8KG2
9PX11KG2

Certifications & Standards

CE (Europe)
cUL Listed
NOM (Mexico)

Energy StarYesCountry of OriginPhilippinesEnvironmental ComplianceRestriction of Hazardous Substances (RoHS)WarrantyLimited Warranty3 Year
