DISPLAYPORT CAT6 EXTENDER KIT TRAN/REC 4K60HZ 4:4:4 POC 230FT TAA

Name: DISPLAYPORT CAT6 EXTENDER KIT TRAN/REC 4K60HZ 4:4:4 POC 230FT TAA
Brand: EATON
SKU: SJ0265
Price: 314.74 USD
Availability: InStock

EATON

PCN#

SJ0265

MFG#

B127A-1A1-BDBDA

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$314.74

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

230 ft Range
2 x Network (RJ
45)
3 x USB
1 x HDMI Out
DisplayPort
2
2
4K
3840 x 2160
Category 6, Category 5, Category 5e
Digital Signage System, Trade Show, Educational Facilities, Lecture Hall, Conference Room, Meeting Room, Retail, HDTV, Desktop PC, Monitor, Gaming
Wall Mountable, Pole
mountable, Rack
mountable, Surface
mountable
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty1 Year

Shipping Weight: 2 lbs.

Eaton Tripp Lite Series DisplayPort over Cat6 Extender Kit, Transmitter/Receiver, 4K 60 Hz, 4:4:4, Power over Cable, 230 ft. (70 m), TAA

Overview

Tech Specs

Extends a 4K AV Transmission up to 230 ft.The B127A-1A1-BDBDA extends 4K signals from a DisplayPort source to a DisplayPort monitor up to 230 feet (70 meters) away via user-supplied Cat6 cabling. By adding a B127A-010-H HDMI repeater or B127A-110-BH transceiver (both sold separately) to the application, you can extend the signal up to 400 feet (122 meters) or 460 feet (140 meters), respectively. Transmits Crystal-Clear 4K Video with Multi-Channel Audio and 4
4
4 ColorThe B127A-1A1-BDBDA supports Ultra HD 4K resolutions up to 3840 x 2160 at 60 Hz with full, rich uncompressed DTS-HD, Dolby TrueHD and 7.1-channel digital audio. Built-in equalization allows you to fine-tune the image quality at the remote display. HDCP 2.2 encryption allows you to stream 4K content with no complications. This extender kit also supports uncompressed 4
4
4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor. Local HDMI Port on Transmitter Supports 4K @ 60 Hz ResolutionTo monitor the video signal being extended to the receiver, connect a 4K display to the transmitter's local HDMI port with a user-supplied HDMI cable (such as P568- or P569-Series). This port does not support multi-resolution capabilities, so the connected monitor must also support 4K at 60 Hz to function properly. Built-In PoC Technology Provides Power to Avoid Bulky External Power BricksPower over Cable (PoC) technology powers either the transmitter or receiver over Cat6 cable. Connect the included power supply at either end to power the entire installation. LEDs on both the transmitter and receiver light up to indicate the system is receiving power and a signal is being transmitted. PoC helps you avoid the hassle of a bulky power brick and gives you the freedom to place one end where needed without worrying about finding a nearby AC outlet. DIP Switches Extend Your Choice of USB or IRThe DIP switches on both the transmitter and receiver can be adjusted to let you choose from the USB 1.1 or bi-directional IR functions. Choose to control the source device via keyboard and mouse or IR remote control from the display end of the installation. Only one function can be extended at a time. Plug-and-Play Operation for Quick Setup and Immediate UseThe included transmitter and receiver work right out of the box with no software required. Mounting hardware is included for installing both units on a wall, pole or 19-inch rack. Connect the transmitter to the source and the receiver to the display with user-supplied DisplayPort cables (such as P580-Series). Then, connect the two units with user-supplied Cat6 Ethernet cable (such as N202-Series). TAA-Compliant for GSA Schedule PurchasesThe B127A-1A1-BDBDA is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.Packaged QuantityBoxProduct TypeVideo Extender Transmitter/ReceiverTechnical InformationConnectivity TechnologyWiredMaximum Operating Distance230 ftVideoGraphics Modes4KMaximum Video Resolution3840 x 2160Interfaces/PortsNetwork (RJ-45)YesHDMI OutYesUSBYesDisplayPortYesNumber of Network (RJ-45) Ports2Number of USB Ports3Number of HDMI Outputs1Remote (IR) Input2Remote (IR) Output2Media & PerformanceTwisted Pair Cable Standard

Category 6
Category 5
Category 5e

Physical CharacteristicsColor FamilyBlackProduct ColorBlackTransmitter Height1.06"Transmitter Width4.53"Transmitter Depth2.46"Receiver Height1.06"Receiver Width4.53"Receiver Depth2.46"Form Factor

Wall Mountable
Pole-mountable
Rack-mountable
Surface-mountable

Transmitter Weight (Approximate)1 lbReceiver Weight (Approximate)1 lbMiscellaneousPackage Contents

DisplayPort over Cat6 Extender Kit, Transmitter/Receiver, 4K 60 Hz, 4
4
4, Power over Cable, 230 ft. (70 m), TAA
External power supply (Input
100-240V, 50/60 Hz, 0.6A; Output
24V 1A) with 4.5 ft. (1.4 m) cord
4x International plug adapters (North America, Europe, U.K. and Australia)
Mounting hardware
Owner's manual

Application/Usage

Digital Signage System
Trade Show
Educational Facilities
Lecture Hall
Conference Room
Meeting Room
Retail
HDTV
Desktop PC
Monitor
Gaming

Country of OriginTaiwanTAA CompliantYesEnvironmental Compliance

Restriction of Hazardous Substances (RoHS)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Waste Electrical and Electronic Equipment Directive (WEEE)

WarrantyLimited Warranty1 Year
