Middle Atlantic NEXSYS Compact PDU - 6 Outlets, 20 Amp PDX-620C

Name: Middle Atlantic NEXSYS Compact PDU - 6 Outlets, 20 Amp PDX-620C
Brand: LEGRAND AV - MIDDLE ATLANTIC
SKU: HB5139
Price: 435.6 USD
Availability: InStock

LEGRAND AV - MIDDLE ATLANTIC

PCN#

HB5139

MFG#

PDX-620C

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$435.60

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

6 x NEMA 5
20R
Rack
mountable, Wall
mountable
Rack

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Middle Atlantic NEXSYS Compact Power Distribution Unit - 20 Amp, 6 Outlet PDU - Multi-Stage Surge Protection

Overview

Tech Specs

Specifications

Manufacturer	Legrand Group
Manufacturer Part Number	PDX-620C
Manufacturer Website Address	http://www.legrand.us
Brand Name	Middle Atlantic
Product Line	NEXSYS
Product Model	PDX-620C
Product Name	NEXSYS Compact Power Distribution Unit - 20 Amp, 6 Outlet PDU
Marketing Information	The Middle Atlantic PDX-620C is a compact NEXSYS PDU designed for 'behind-the-display' applications, particularly digital signage. It features (6) NEMA 5-20R outlets and operates at 20A. The PDU offers flexible mounting options with both clamp and L-brackets, which can be easily attached to a Lever Lock plate for tool-free installation inside a rack, kiosk, or in-wall box. It includes multi-stage MOV surge protection with 3 stages and visual indicators of surge status on the front and side. The selectable on/off voltage protection from the dry contact port helps safeguard sensitive equipment from over/under voltage scenarios by automatically turning off the outlets during such events and restoring them once the power is within the acceptable range. The PDU also supports cleaner cable management with a standard 2ft power cord and allows for the use of both outlets without obstruction, thanks to the orientation designed for easier plugging of DC transformers (wall warts).
Product Type	PDU

Technical Information

Receptacle Type	NEMA 5-20R
Receptacle Detail	6 x NEMA 5-20R
Protection Type	Surge Protection
Features	Compact

Power Description

Input Current

20 A

Physical Characteristics

Mount Type	Rack-mountable Wall-mountable
Form Factor	Rack

Miscellaneous

Country of Origin

Malaysia
