OMADA 28-PORT GIGABIT SWITCH OMADA 28-PORT GIGABIT SWITCH

Name: OMADA 28-PORT GIGABIT SWITCH OMADA 28-PORT GIGABIT SWITCH
Brand: TP-LINK SYSTEMS INC.
SKU: XS4055
Price: 299.99 USD
Availability: InStock

TP-LINK SYSTEMS INC.

PCN#

XS4055

MFG#

ES228GMP

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$299.99

Extended & Accidental Damage Protection Plans Available Details

2-Year $40.99

3-Year $53.99

Free Shipping

Estimated Shipment:

Product Highlights:

Omada 28
Port Gigabit Easy Managed Switch with 24
Port PoE+ PORT: 24× Gigabit PoE+ Ports, 2x Gigabit Non
PoE Ports, 2× Gigabit SFP Ports SPEC: 802.3at/af, 384W PoE Power, 1U 19
inch Rack
mountable Steel Case FEATURE: Integration with Omada SDN Controller and Omada Cloud Essentials, Fast PoE, Perpetual PoE, Flow Control, Loopback Detection, Port Isolation, Port Mirroring, LAG, VLAN, IGMP Snooping, QoS, Storm Control

Product Condition: New and Factory Fresh

Shipping Weight: 14 lbs.

TP Link Omada ES228GMP - Omada 28-Port Gigabit Easy Managed Switch with 24-Port

Overview

Tech Specs

Specifications

Manufacturer	TP-LINK Technologies Co., Ltd
Manufacturer Part Number	ES228GMP
Manufacturer Website Address	http://www.tp-link.com/us
Brand Name	Omada
Product Model	ES228GMP
Product Name	28-Port Gigabit Easy Managed Switch with 24-Port PoE+
Marketing Information	28× Gigabit Ports (24× PoE+, 2× RJ45, 2× SFP) 384W Total PoE Budget Up to 250m PoE Transmission Easy Centralized Management Automatic Loop Prevention PoE Auto Recovery Traffic Separation Traffic Prioritization Omada Cloud Essentials - A Free and Easy Cloud-Based Network Management Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses. Lifetime Free Cloud without Any Additional Fees Exists Entirely in the Cloud. No Hardware or Software Controller Needed Cloud Centralized Management for Multiple Sites Access Anytime via Omada App or Web Easy Setup, Use, and Maintenance Unlimited Management Scale Zero-Touch Provisioning (ZTP) without Unboxing Seamlessly Upgrade to Omada Cloud Standard with a Subscription Abundant Functions for Reliable Surveillance Networking Transmission Distance up to 250 m Priority Video Quality Guaranteed Secure Traffic Separation via Port Isolation PoE Auto Recovery Multiple Application Scenarios \| Surveillance Works with IP Cameras Wi-Fi Coverage Works with Access Points Wired Connections Works with Non-PoE Devices such as PCs and Printers
Packaged Quantity	1
Product Type	Ethernet Switch

Technical Information

Features

Fanless
Plug and Play
Remote/Cloud Management
Zero-Touch Provisioning (ZTP)
Intelligent monitoring
Loop Protection
VLAN Segmentation
Surge Protection
Broadcast Storm Control
Multicast Storm Control
Unicast Storm Control
Loopback Detection

Interfaces/Ports

Total Number of Network Ports	26
Network (RJ-45)	Yes
Port/Expansion Slot Details	24 x Gigabit Ethernet PoE+ 2 x Gigabit Ethernet Network 2 x Gigabit Ethernet Expansion Slot

Media & Performance

Media Type Supported	Twisted Pair Optical Fiber
Ethernet Technology	Gigabit Ethernet
Network Technology	10/100/1000Base-T 1000Base-X
Maximum Data Transfer Rate	128 MB/s

I/O Expansions

Total Number of Expansion Slots	2
Expansion Slot Type	SFP (mini-GBIC)
Number of SFP Slots	2

Network & Communication

Layer Supported	2
Networking Standards	IEEE 802.3i IEEE 802.3u IEEE 802.3ab IEEE 802.3x IEEE 802.1p IEEE 802.1Q IEEE 802.1ab IEEE 802.3af IEEE 802.3at

Management & Protocols

Manageable	Yes
Switch Management Type	Easy Managed

Reliability

MTBF	224143 Hour

Power Description

PoE (RJ-45) Port	Yes
PoE Budget	384 W
Input Voltage	120 V AC 230 V AC
Frequency	50 Hz 60 Hz
Power Source	Power Supply
Power Consumption	454.80 W

Physical Characteristics

Product Material	Metal Steel
Compatible Rack Unit	1U
Form Factor	Desktop Rack-mountable
Height	1.7"
Width	17.3"
Depth	13"

Miscellaneous

Package Contents	28-Port Gigabit Easy Managed Switch with 24-Port PoE+ Power Cord Mounting Brackets Rubber Feet Screws Installation Guide
Application/Usage	Surveillance Network Wireless Access Point Outdoor Printer IP Camera Desktop Small Business
Certifications & Standards	FCC CE
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
