XPANSTOR 12R 12 BAY RACKMOUNT NAS EXPANDER DISCLESS 12 X SAS3

Easily Configure Using Storage Manager The Xpanstor 12R appears in ADM natively and drives appear within Storage Manager, which makes managing and configuring the attached expansion unit easy. Use Storage Manager to set up RAID configurations as well as utilize snapshot features to further enhance data security and reliability. Dual Redundant Power Supplies and Hot-Swappable Fan Design The Xpanstor 12R is equipped with two 650W redundant power supplies and three hot-swappable fans, which increases overall operational efficiency and fault tolerance. Both power supplies can automatically switch to the other in the event one fails, ensuring continuous operation and data security. The hot-swappable fan design allows for fan replacement without downtime, effectively reducing maintenance and upgrade costs. First-Class Product Warranty The Xpanstor 12R comes with a five year warranty. ASUSTOR continues to make customer service a priority in providing the highest standard of after-sales service and technical support.Packaged Quantity1Product TypeNAS Storage SystemStorageNumber of Hard Drives Supported12Number of Hard Drives Installed0Number of Solid State Drive Supported12Number of Solid State Drive Installed0Flash Memory Capacity2 MBI/O ExpansionsNumber of Total Expansion Bays12Number of 2.5"/3.5" Bays12ControllersController Type

• Serial ATA/600
• Serial Attached SCSI (SAS)

RAID SupportedYesRAID Levels0, 1, 5, 6, 10, JBODInterfaces/PortsNumber of SAS Ports (External)2SoftwareOperating SystemADM 4.2.4Power DescriptionNumber of Power Supplies Installed2Maximum Power Supply Wattage650 WRedundant Power SupplyYesPhysical CharacteristicsHeight3.5"Width17.2"Depth25.5"Form FactorRack-mountableRack Height2UWeight (Approximate)28.99 lbMiscellaneousPackage Contents

• XPANSTOR 12 (AX7012R)
• 2 x AC Power Cord
• 1 x SFF-8644
• AX-Rail
• 48 x Flat Head Screw (for 2.5" HDD)

WarrantyLimited Warranty5 Year
