Black Box Agility KVM-Over-IP Matrix, Dual-Head DVI-D, USB 2.0, KVM Receiver

Name: Black Box Agility KVM-Over-IP Matrix, Dual-Head DVI-D, USB 2.0, KVM Receiver
Brand: BLACK BOX
SKU: 8571AD
Price: 1875.72 USD
Availability: OutOfStock

BLACK BOX

PCN#

8571AD

MFG#

ACR1020A-R

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

Estimated Shipment:

Product Highlights:

2 Local User(s)
330 ft Range
Full HD
1920 x 1080 Maximum Video Resolution
2 x Network (RJ
45)
4 x USB
2 x DVI
TAA Compliant

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 4 lbs.

Black Box Agility KVM-Over-IP Matrix, Dual-Head DVI-D, USB 2.0, KVM Receiver

Overview

Tech Specs

Specifications

Manufacturer	Black Box Corporation
Manufacturer Part Number	ACR1020A-R
Manufacturer Website Address	http://www.blackbox.com
Brand Name	Black Box
Product Name	Agility KVM-Over-IP Matrix, Dual-Head DVI-D, USB 2.0, KVM Receiver
Marketing Information	The Agility IP-Based KVM Extension system transmits Dual Head DVI-D video, USB, USB2.0 and audio signals via an Ethernet local area network (LAN). Send signals up to 330 feet (100 m), or even farther with the addition of network switches. Use the Agility Controller to enable remote secure configuration of transmitters and receivers via a Web browser. The Agility system offers a flexible topology of switching and extension. Use it in point-to-point KVM extension, to multicast HD video, or for single-target sharing. Agility transmits pixel-perfect video with no-loss compression, minimizing bandwidth use while maximizing user experience. Maximum resolution is 1920x1080.
Product Type	KVM Extender Receiver

Technical Information

Connectivity Technology	Wired
Number of Local Users Supported	2
Maximum Operating Distance	330 ft
Device Type	KVM Extender

Video

Graphic Mode	Full HD
Maximum Video Resolution	1920 x 1080

Interfaces/Ports

Network (RJ-45)	Yes
USB	Yes
DVI	Yes
Headphone	Yes
Microphone	Yes
Number of Network (RJ-45) Ports	2
Number of USB Ports	4
Number of DVI Ports	2

Physical Characteristics

Receiver Height	1.76"
Receiver Width	7.92"
Receiver Depth	4.80"
Receiver Weight (Approximate)	1.76 lb

Miscellaneous

Additional Information	This product works with: 192-Endpoint KVM-over-IP Matrix iPATH Controller 24-Endpoint KVM-over-IP Matrix iPATH Controller 288-Endpoint KVM-over-IP Matrix iPATH Controller 48-Endpoint KVM-over-IP Matrix iPATH Controller 96-Endpoint KVM-over-IP Matrix iPATH Controller KVM-Over-IP Matrix, Dual-Head DVI-D,USB 2.0, KVM Transmitter
Environmentally Friendly	Yes
Environmental Certification	WEEE RoHS
Country of Origin	United Kingdom
TAA Compliant	Yes

Warranty

Limited Warranty

2 Year
