CHASSISW/8GPUNOPSUNORAID/CBLENOHDDMODNOCPUMOD REMANUFACTURED

Name: CHASSISW/8GPUNOPSUNORAID/CBLENOHDDMODNOCPUMOD REMANUFACTURED
Brand: CISCO
SKU: 6147BI
Price: 112331.75 USD
Availability: OutOfStock

CISCO

PCN#

6147BI

MFG#

UCSC-C480-M5ML8-RF

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

Estimated Shipment:

Product Highlights:

Intel C620 Chip
3 TB DDR4 SDRAM DDR4
2666/PC4
21300 Maximum RAM Support
24 Total Memory Slots
12Gb/s SAS RAID Supported Controller
NVIDIA 32 GB Graphic(s)
24 2.5" Bay(s)
Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze)
10 Gigabit Ethernet
3 USB 3.0 Port(s)

Product Condition: New and Factory Fresh

Shipping Weight: 154 lbs.

Cisco Barebone System - Refurbished - 4U Rack-mountable - 2 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Cisco Systems, Inc
Manufacturer Part Number	UCSC-C480-M5ML8-RF
Manufacturer Website Address	http://www.cisco.com
Brand Name	Cisco
Product Series	C480 ML M5
Product Name	UCS C480 ML M5 Barebone Sysetm
Marketing Information	The Cisco UCS C480 ML, a purpose-built Server for Deep Learning, is a four-rack-unit (4RU) server supporting Intel® Xeon® processor scalable family CPUs with 8 NVIDIA Tesla V100-32GB Tensor Core GPUs with NVLink Interconnect. It supports up to 3 terabytes (TB) of double-data-rate 4 (DDR4) memory1 in 24 slots, up to 24 small form factor (SFF) hot-swappable2 SAS/SATA SSD/HDD, up to 6 PCIe NVMe disk drives and upto two internal M.2 drives. 4 PCI Express (PCIe) expansion slots support Cisco UCS C-Series and partner network adapters, with additional I/O provided by two 10Gbase-T LOM ports and one 1GbE dedicated out-of-band (OOB) management port. A separate PCIe slot is reserved inside the chassis for a RAID controller card
Product Condition	Refurbished
Product Type	Barebone System

Processor

Number of Processors Supported	2
Processor Supported	Xeon Platinum Xeon Gold Xeon Silver Xeon Bronze
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	C620

Memory

Maximum Memory Supported	3 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2666/PC4-21300
Total Number of Memory Slots	24

Controllers

Controller Type	12Gb/s SAS
RAID Supported	Yes

Display & Graphics

Graphics Controller Manufacturer	NVIDIA
Graphics Memory Capacity	32 GB

Network & Communication

Ethernet Technology

10 Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	24
Number of 2.5" Bays	24
Total Number of Expansion Slots	4
Number of PCI Express x16 Slots	4

Interfaces/Ports

Total Number of USB Ports	4
Number of USB 3.0 Ports	3

Power Description

Input Voltage

120 V AC
230 V AC

Physical Characteristics

Form Factor	Rack-mountable
Rack Height	4U
Height	6.9"
Width	19"
Depth	32.7"
Weight (Approximate)	146 lb

Miscellaneous

Country of Origin

United States
