3YR NC BRANCH 5G ADAPTER ESS PLAN W1850 ADAPTER, GLOBAL

Designed for Enterprise-Class BusinessWhile the performance of 5G is top of mind, the W-Series was also designed with enterprise-class standards for high scalability, comprehensive management, and security. Representing the latest available 5G standards which are a collection of spectrum, technologies, and network infrastructure enhancements, the Ericsson 5G edge networking service and endpoints accommodate the diverse deployments of an organization with hundreds or even tens of thousands of sites. Carrier-Class ConnectivityAlthough each network operator conforms to 3GPP standards, they implement those standards differently to gain optimal efficiency and performance from their network. Additionally, software from modem manufacturers is designed to serve multiple operators within broad markets. The W-Series uses a customized software-defined modem, pre-programmed endpoints, and multilevel integrity testing to predict vulnerable connections and deliver carrier-class connectivity. 5G Spectrum SolutionsThe W-Series portfolio supports all spectrum layers ensuring that organizations have the right solution for every location. The W1850 5G adapters support low- and mid-band layers. Support for a Full Range of Cellular TechnologiesEricsson 5G solutions support all cellular generations, from 4G LTE to Gigabit-Class LTE to 5G - with the ability to gracefully transition tens of thousands of sites between generations as technology becomes available in individual locations. Complete Lifecycle ManagementEricsson 5G solutions help enterprises minimize complexity from installation to troubleshooting with tools and features such as the mobile installation application, the captive modem feature, 5G tools demonstrate 5G service value, and Out-of-Band Management. Intelligent Hybrid WAN ConnectivityEricsson 5G solutions deliver effortless wireless endpoint management in a "wired-first SD-WAN" environment and provides all-in-one capabilities (routing, embedded wireless, and foundational SD-WAN) in a "wireless-first SD-WAN" deployment.Product TypeModem/Wireless RouterTechnical InformationNR Band (5G)

• n1
• n2
• n3
• n5
• n7
• n8
• n12
• n14
• n20
• n25
• n28
• n30
• n38
• n40
• n41
• n48
• n66
• n70
• n71
• n75
• n76
• n77
• n78

LTE Band (4G)

• B1
• B2
• B3
• B4
• B5
• B7
• B8
• B12
• B13
• B14
• B20
• B28
• B29
• B30
• B32
• B66
• B71
• B38
• B42
• B43
• B46
• B48

MU-MIMO TechnologyYesWireless SpecificationsBroadband Transmission Technology

• Ethernet
• Cellular

Cellular Generation5GCellular Data Connectivity Technology

• HSPA+
• WCDMA
• LTE
• 5G NR

Total Number of Antennas4Number of External Antennas4Interfaces/PortsTotal Number of Network Ports2Number of Network (RJ-45) Ports2USBYesUSB StandardUSB 2.0 Type ANetwork & CommunicationEthernet Technology2.5 Gigabit EthernetMulti-SIM SupportedYesNumber of SIM Card Supported2SIM Size SupportedNanoPhysical CharacteristicsForm Factor

• Desktop
• Wall Mountable

Height1.5"Width6.5"Depth6.5"Weight (Approximate)1.90 lb
