PDU POWER CORD C13 P-LOCK C14 N.A. EU RATED 10A 250V 6FT BLACK

Name: PDU POWER CORD C13 P-LOCK C14 N.A. EU RATED 10A 250V 6FT BLACK
Brand: EATON
SKU: SR0130
Price: 46.38 USD
Availability: InStock

EATON

PCN#

SR0130

MFG#

P004-E06

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$46.38

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $14.99

1-Year $10.99

Estimated Shipment:

Product Highlights:

For PDU, Server, Switch, Computer, Rack, Cabinet, Printer, Workstation, Monitor, UPS, HDTV
18 Gauge
120 V AC / 10 A, 230 V AC
Black
6 ft Cord Length
IEC 60320 C13 / IEC 60320 C14
North America, Europe

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

Eaton Tripp Lite Series PDU Power Cord, C13 to P-Lock C14 - North America and Europe Rated, 10A, 250V, 18AWG, 6 ft. (1.83m), Black

Overview

Tech Specs

P-Lock Connector Reduces Risk of Costly DowntimePlug the P004-E06's P-Lock C14 connector into a compatible PDU, such as Eaton's line of PDUs with P-Lock C13 and C39 outlets, for a secure connection that reduces the risk of accidental disconnections in a crowded rack enclosure or cabinet. Locking tabs on either side of the connector click into place for a secure connection.Product TypeStandard Power CordTechnical InformationFirst End Connector TypeIEC 60320 C13First End Connector Detail1 x 3-pin IEC 60320 C13 FemaleSecond End Connector TypeIEC 60320 C14Second End Connector Detail1 x 3-pin IEC 60320 C14 MaleDevice Supported

PDU
Server
Switch
Computer
Rack
Cabinet
Printer
Workstation
Monitor
UPS
HDTV

LocalizationInternationalGauge18Number of Conductors3FeaturesP-LockPower DescriptionVoltage Rating

120 V AC
230 V AC

Current Rating10 APhysical CharacteristicsColor FamilyBlackProduct ColorBlackJacket Material

Polyvinyl Chloride (PVC)
Service Junior Thermoplastic (SJT)

Height10"Width8"Depth0.5"Cord Length6 ftEnvironmental ConditionsMinimum Operating Temperature23°F (-5°C)Maximum Operating Temperature158°F (70°C)Minimum Storage Temperature14°F (-10°C)Maximum Storage Temperature140°F (60°C)MiscellaneousCertifications & Standards

UL Standards
VDE Standards
cUL Listed
CE (Europe)
UKCA

Country of OriginChinaEnvironmental Compliance

Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS) 3
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

WarrantyLimited WarrantyLifetime
