POWER CORD C20 C21 HEAVY-DUTY 20A 250V 12 AWG 2.5FT BLUE

Recommended for High-Temperature EnvironmentsThe P035-2P5-ABL can be used to connect a blade server, large router or network switch with a C22 inlet, usually found on high-powered, high-temperature (overall operating temperature maximum 105°C/221°F) equipment, to a PDU or UPS system. It's an ideal upgrade to a power cord with improved temperature threshold for data center applications in which temperature control and fire safety are high priorities. Blue Jacket Helps Avoid Misidentification That Can Cause Costly DowntimeThe UL-listed cable has a blue PVC jacket with fully molded blue ends, which is easy to identify quickly in a crowded PDU or UPS system and helps prevent the cable from becoming accidentally disconnected.Product TypeStandard Power CordTechnical InformationFirst End Connector TypeIEC 60320 C20First End Connector Detail1 x 3-pin IEC 60320 C20 MaleSecond End Connector TypeIEC 60320 C21Second End Connector Detail1 x 3-pin IEC 60320 C21 FemaleDevice Supported

• Network Switch
• PDU
• UPS
• Switch
• Server
• Network Device
• Rack
• Blade Server
• Router

LocalizationNorth AmericaGauge12Number of Conductors3Features

• Heavy Duty
• High Temperature Rating

Power DescriptionVoltage Rating250 V ACCurrent Rating20 APhysical CharacteristicsColor FamilyBlueProduct ColorBlueJacket MaterialPolyvinyl Chloride (PVC)Height12.8"Width8.9"Depth0.5"Cord Length2.50 ftWeight (Approximate)0.62 lbEnvironmental ConditionsMinimum Operating Temperature-4°F (-20°C)Maximum Operating Temperature221°F (105°C)Minimum Storage Temperature-4°F (-20°C)Maximum Storage Temperature221°F (105°C)MiscellaneousCountry of OriginVietnamEnvironmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)WarrantyLimited WarrantyLifetime
