POWER CORD C14 C21 HEAVY-DUTY 15A 250V 14 AWG 6FT RED

Recommended for High-Temperature EnvironmentsThe P037-006-ARD can be used to connect a blade server, large router or network switch with a C22 inlet, usually found on high-powered, high-temperature (overall operating temperature maximum 105°C/221°F) equipment, to a PDU or UPS system. It's an ideal upgrade to a power cord with improved temperature threshold for data center applications in which temperature control and fire safety are high priorities. Red Jacket Helps Avoid Misidentification That Can Cause Costly DowntimeThe UL-listed cable has a red PVC jacket with fully molded red ends, which is easy to identify quickly in a crowded PDU or UPS system and helps prevent the cable from becoming accidentally disconnected.Product TypeStandard Power CordTechnical InformationFirst End Connector TypeIEC 60320 C14First End Connector Detail1 x 3-pin IEC 60320 C14 MaleSecond End Connector TypeIEC 60320 C21Second End Connector Detail1 x 3-pin IEC 60320 C21 FemaleDevice Supported

• Computer
• Server
• UPS
• PDU
• Switch
• Rack
• Network Device
• Blade Server
• Router
• Network Switch

LocalizationNorth AmericaNumber of Conductors3Features

• Heavy Duty
• High Temperature Rating

Power DescriptionVoltage Rating250 V ACCurrent Rating15 APhysical CharacteristicsColor FamilyRedProduct ColorRedJacket Material

• Polyvinyl Chloride (PVC)
• Service Junior Thermoplastic (SJT)

Height12.8"Width8.9"Depth0.5"Cord Length6 ftEnvironmental ConditionsMinimum Operating Temperature-4°F (-20°C)Maximum Operating Temperature221°F (105°C)Minimum Storage Temperature-4°F (-20°C)Maximum Storage Temperature221°F (105°C)MiscellaneousCountry of OriginVietnamEnvironmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE)WarrantyLimited WarrantyLifetime
