ELO 1304L 13.3-INCH WIDE LCD DESKTOP FULL HD 1920 X 1080 PROJECT

Name: ELO 1304L 13.3-INCH WIDE LCD DESKTOP FULL HD 1920 X 1080 PROJECT
Brand: ELO
SKU: 610J41
Price: 545.77 USD
Availability: InStock

ELO

PCN#

610J41

MFG#

E969110

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$545.77

Extended & Accidental Damage Protection Plans Available Details

2-Year $66.99

3-Year $89.99

Free Shipping

Estimated Shipment:

Product Highlights:

13.3" Viewable
Projected Capacitive
10 Point(s) Multi
touch Screen
1920 x 1080
Full HD
Thin Film Transistor (TFT)
16.2 Million Colors
270 Nit
Speakers
HDMI
USB
DisplayPort
USB Type
C
Black
USB Hub

Product Condition: New and Factory Fresh

Shipping Weight: 11 lbs.

Elo 1304L 13" Class LCD Touchscreen Monitor - 16:9 - 27 ms

Overview

Tech Specs

Specifications

Manufacturer	Elo Touch Solutions, Inc
Manufacturer Part Number	E969110
Manufacturer Website Address	http://www.elotouch.com
Brand Name	Elo
Product Model	1304L
Product Name	1304L Widescreen Touchscreen LCD Monitor
Marketing Information	1304L 13-inch Touchscreen Monitor The 1304L touch monitor delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity. With state-of-the-art optical bonding and IP54-sealed design, the 13" touch monitor offers a feature-rich platform and the versatility to extend across a diverse range of applications from point-of-sale, self-service and kitchen display systems to warehouse automation, access control and HMI. Create the perfect payment stack with the 13" touchscreen. Easily pair the 13-inch touchscreen monitor with one of Elo's integrated payment devices - from Elo Pay mobile computers to the Elo Pay 7" , the 1304L offers the perfect compact touch display with the connectivity you need at the point of sale. State of the art optical viewing. Designed with high quality optical bonding, anti- glare coverglass and low-blue light settings - the 1304L 13-inch touchscreen monitor brings the best-in-class solution for viewing comfort and clarity. Secure yourcables into place. Never lose your port covers and screws with the security of the captive design. With a port cover that locks into place, cables are less prone to becoming disconnected, resulting in minimal disruptions to the device. Connect accessories to the edge. Elo Edge Connect™ offers an expansive lineup of accessories that seamlessly attach to the edge of the display including - EMVs, barcode scanners, status lights, cameras, RFID, MSR, fingerprint scanner and more. Navigate the OSD directly on the touchscreen. The on-screen display (OSD) controls are now directly on the touchscreen - making navigation easier while still offering OSD lock security. Expand the possibilities with touch through. Elo's TouchPro PCAP monitors feature touch through capability, supporting use with gloves and additional layers of films and filters to meet specific industry requirements.
Product Type	LCD Touchscreen Monitor

Technical Information

Screen Size Class	13"
Viewable Screen Size	13.3"
Screen Mode	Full HD
Panel Technology	Thin Film Transistor (TFT)
Response Time	27 ms
Aspect Ratio	16:9
Horizontal Viewing Angle	170°
Vertical Viewing Angle	170°
Placement	Tabletop
Features	Anti-glare On-screen Display (OSD) Color Temperature Selection Low Blue Light ComfortView Scratch Resistant On-screen Display (OSD) Lock
Vertical Frequency	60 Hz
Ingress Protection (IP) Rating	IP54
Impact Protection (IK) Rating	IK08
Active Display Area (H x V)	11.50" x 6.50"
On Screen Display (OSD) Controls	Volume Mute Sharpness Color Temperature Brightness Contrast

Video

Maximum Resolution	1920 x 1080
Color Supported	16.2 Million Colors
Native Contrast Ratio	600:1
Brightness	270 Nit
Maximum Refresh Rate	60 Hz
Brightness (Peak)	300 Nit

Audio

Speakers	Yes
Number of Speakers	2

Touchscreen Information

Touchscreen Type	Projected Capacitive
Multi-touch Screen	Yes
Number of Simultaneous Touchpoints	10

Interfaces/Ports

HDMI	Yes
USB	Yes
DisplayPort	Yes
USB Type-C	Yes
Total Number of HDMI Ports	1
Number of USB Ports	6
Number of DisplayPorts	1
Total Number of USB Type-C Ports	1
USB Type-C (Power Delivery)	18 W
Number of Micro USB Ports	4

Built-in Devices

USB Hub

Environmental Conditions

Operating Temperature Range	32°F (0°C) to 104°F (40°C)
Operating Humidity Range	20% to 80% (Non-condensing)

Physical Characteristics

VESA Mount Compatible	Yes
VESA Mount Standard	75 x 75
Color Family	Black
Product Color	Black
Height	7.7"
Width	12.6"
Depth	1"
Weight (Approximate)	2.64 lb
Weight with Stand (Approximate)	5.28 lb

Miscellaneous

Energy Star

Yes
