EXTREMESWITCHING 5320 24X10/100/1000BASET FDX/HDX POE+ 8X10G UNPOPULATED SFP+ MA

Cloud-Based Network ManagementThe 5320 can be managed by ExtremeCloud IQ and ExtremeCloud IQ Site Engine for centralized switch management, giving you a consolidated view of users, devices, and applications across wired and wireless networks for efficient inventory and network topology management. ExtremeCloud IQ enables zero touch provisioning, allowing you to quickly bring new 5320 switches online as well as select the OS persona.Alternatively, 5320 on-box management can be done manually via a web based GUI or generic command-line interface (CLI). Ethernet Fabric ServicesThe 5320 supports a variety of Ethernet Fabric services, including Extreme's Fabric Connect when running Fabric Engine and Extreme's IP Fabric when running Switch Engine. It also supports Fabric Attach for automated connection to either Layer 2 or Layer 3 Fabric services.Extreme's Fabric Connect and IP Fabric enable the creation of virtualized networks that automate network operations, simplify network provisioning, and enhance security, all while reducing the strain on network and IT personnel. Universal Hardware Platform The 5320 comes with a dual-persona capability, allowing you to choose your OS. Either the Switch Engine (EXOS) or Fabric Engine (VOSS) OS can be selected at switch start-up or changed at a later stage. When selected, the switch assumes the features and capabilities of that OS.5320 OS selection can also be automated with ExtremeCloud IQ so that the desired OS can be automatically loaded at switch start-up, facilitating remote OS enablement. Power Over Ethernet (PoE)All 5320 models support 30W PoE that conforms with IEEE 802.3at. This enables the 5320 to address the needs of powered edge devices, while eliminating the need for additional electrical cabling and circuits. In addition, 5320 PoE models support perpetual and fast PoE for even more efficient and reliable powered edge device operation. Audio Video BridgingThe 5320 Series supports IEEE 802.1 Audio Video Bridging (AVB) when running Switch Engine OS. This allows 5320 models to deliver reliable, real-time audio/ video transmission over Ethernet, meeting the quality of service required for today's high-definition, time-sensitive multimedia streams. Extended Temperature OperationThe 5320 Series offers 24- and 48-port switch models that support extended temperature operation1 of 0°C to 60°C. The 48-port switch model provides a combination of Fiber and Copper ports enabling flexible deployment use cases. Both switch models include 4x10G SFP+ for uplinks and/or stacking. The extended temperature switch models come with one fixed power supply and support an optional external Redundant Power Supply (RPS) as well. Silent OperationSilent mode operation at temperatures up to 35°C is supported on 5320 16-port AC and DC-powered models. This makes these models ideal for classrooms, hospitality suites, retail sites, or other noise sensitive environments, especially outside of the wiring closet environment.Product TypeEthernet SwitchTechnical InformationFeaturesBuilt-in FanInterfaces/PortsTotal Number of Network Ports24Uplink PortYesModularYesStack PortYesNetwork (RJ-45)YesPort/Expansion Slot Details

• 24 x Gigabit Ethernet PoE+
• 8 x 10 Gigabit Ethernet Expansion Slot

Media & PerformanceMedia Type Supported

• Optical Fiber
• Twisted Pair

Ethernet Technology

• Gigabit Ethernet
• 10 Gigabit Ethernet

Network Technology

• 10/100/1000Base-T
• 10GBase-X

I/O ExpansionsTotal Number of Expansion Slots8Expansion Slot TypeSFP+Number of SFP+ Slots8Network & CommunicationLayer Supported2Networking Standards

• IEEE 802.3at
• IEEE 802.3ab
• IEEE 802.3
• IEEE 802.3ae
• IEEE 802.3az

Management & ProtocolsManageableYesPower DescriptionPoE (RJ-45) PortYesPoE Budget370 WPower SourcePower SupplyNumber of Power Supplies Installed1Power Consumption480 WPhysical CharacteristicsCompatible Rack Unit2UForm FactorRack-mountableHeight1.7"Width17.3"Depth11"Weight (Approximate)8.82 lbMiscellaneousPackage Contents

• 5320 24-port 30W PoE Switch
• 2-post Rack-mount Kit

Application/UsageNetworkTAA CompliantYes
