HPE ANW 8325H 16C FB 4FS 2PS SW PL-L1

The HPE Aruba Networking CX 8325 Switch Series serves as both a campus (core and aggregation) and data center (ToR and EoR) switch. This game-changing solution offers an innovative approach to dealing with network demands in the mobile, cloud, and IoT era. CX 8325 Switch Series is based on AOS-CX, with its microservices style modular architecture, REST APIs, Python scripting capabilities and NAE is a modern software system that automates and simplifies critical and complex network tasks, delivers enhanced fault tolerance and facilitates zero-service disruption during planned or unplanned control-plane events. CX 8325 provides line rate 1GbE, 10GbE, 25GbE, and 40GbE in a compact 1U form factor.

CX 8325P, delivers key solutions for providers in their 5G (Radio Access Network) and edge computing deployments. CX 8325H are highperformance 1/10/25/40/100G half-width switches ideal for smaller, edge or colocation data centers, and wide variety of compute and storage networking use cases.|

What's new

• High-performance with 2,000 Mpps. HPE Aruba Networking designed the data center for core/aggregation in the campus or top-of-rack (ToR) or End of Row (EoR).
• AOS-CX delivers automation and programmability using built-in REST APIs and Python scripts. High availability with industry-leading VSX redundancy, and redundant power supplies and fans.
• Intelligent monitoring, visibility, and remediation with HPE Aruba Networking Network Analytics Engine and dynamic VXLAN for deep segmentation in data center and campus networks with BGPEVPN.
• Compact 1U switches with 1GbE, 10GbE, 25GbE, 40GbE, and 100GbE connectivity. Advanced layer 2/3 feature set includes BGP, OSPF, VRF, VXLAN, and IPv6.
• CX 8325P-32C switch supports PTP (1588v2), Class C (G.8275.1/G.8275.2), Synchronous Ethernet (SyncE, G.8262.1), Global Navigation Satellite System (GNSS) to support Telco Boundary Clock.

CX 8325H has two variations:

• 2.16Tbps half-width fixed switch that supports 18 ports of 1/10/25 and 4 ports of 40/100GbE
• 4Tbps half-width fixed switch that supports 16 ports of 40/100 GbE |

Features

Game-changing Business Agility

The HPE Aruba Networking CX 8325 Switch Series is a campus core and aggregation switch and data center (ToR) solution with an innovative and powerful approach to dealing with the cross-domain demands of the mobile, cloud, and IoT era.

• Remote Monitoring (RMON)
• Access Control List
• Synchronous Ethernet (SyncE)
• Scripting
• Hot-swappable

• 16 x 100 Gigabit Ethernet QSFP28 Expansion Slot
• 2 x 10 Gigabit Ethernet SFP+ Expansion Slot
• 1 x RJ-45 Console Port
• 1 x USB Type-C Console Port
• 1 x RJ-45 Management Port
• 1 x USB Type A AUX

• 10 Gigabit Ethernet
• 40 Gigabit Ethernet
• 100 Gigabit Ethernet
• Gigabit Ethernet
• 25 Gigabit Ethernet

• 40GBase-X
• 100GBase-X
• 10GBase-X
• 2500Base-T
• 1000Base-X

• QSFP28
• SFP+

• IEEE 802.1ab
• IEEE 802.1ak
• IEEE 802.1AX
• IEEE 802.1D
• IEEE 802.1p
• IEEE 802.1s
• IEEE 802.1Q
• IEEE 802.1t
• IEEE 802.1w
• IEEE 802.3ad
• IEEE 802.3ba
• IEEE 802.3x
• IEEE 802.3z

• 120 V AC
• 230 V AC

• Power Supply
• AC

• Rack-mountable
• Compact

• CX 8325H 16p QSFP28 40G/100G Front-to-Back 4xFan 2xPSU Switch
• 4 x Fan
• 2 x Power Supply Unit

• Network
• Campus
• Data Center
• Enterprise
