Lenovo ThinkSystem DE4000H SAS Hybrid Flash Array LFF

Name: Lenovo ThinkSystem DE4000H SAS Hybrid Flash Array LFF
Brand: LENOVO
SKU: 07YF94
Price: 13262.87 USD
Availability: InStock

LENOVO

PCN#

07YF94

MFG#

7Y741009NA

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

Estimated Shipment:

Product Highlights:

12 x HDD Supported
0 x HDD Installed
12 x SSD Supported
0 x SSD Installed
2 x 12Gb/s SAS Controller
RAID Supported
0, 1, 3, 5, 6, 10 RAID Levels
12 x Total Bays
12 x 3.5" Bay
Gigabit Ethernet
2 USB Port(s)
FCP, SSH, SMI
S, SNMP, SSL, LDAP
4 SAS Port(s) External
2U
Rack
mountable

Product Condition: New and Factory Fresh

Limited Warranty3 YearAdditional Warranty InformationThree-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.

Shipping Weight: 1 lbs.

Lenovo ThinkSystem DE4000H SAS Hybrid Flash Array LFF

Overview

Tech Specs

Specifications

Manufacturer	Lenovo Group Limited
Manufacturer Part Number	7Y741009NA
Manufacturer Website Address	http://www.lenovo.com/us/en/
Brand Name	Lenovo
Product Line	ThinkSystem
Product Series	DE
Product Model	DE4000H
Product Name	ThinkSystem DE4000H SAS Hybrid Flash Array LFF
Marketing Information	Lenovo ThinkSystem DE4000H is a scalable, hybrid entry-level storage system that is designed to provide performance, simplicity, capacity, security, and high availability for medium to large businesses. It delivers enterprise-class storage management capabilities with a wide choice of host connectivity options, flexible drive configurations, and enhanced data management features. The ThinkSystem DE4000H is a perfect fit for a wide range of enterprise workloads, including big data and analytics, video surveillance, technical computing, backup and recovery, and other storage I/O-intensive applications. ThinkSystem DE4000H models are available in a 2U rack form-factor with 24 small form-factor (2.5-inch SFF) drives (2U24 SFF), 12 large form-factor (3.5-inch LFF) drives (2U12 LFF), or a 4U rack form-factor with 60 LFF drives (4U60 LFF) and include two controllers, each with 8 GB or 32 GB memory for a system total of 16 GB or 64 GB. Host interface cards provide 12 Gb SAS, 10/25 Gb iSCSI, or 8/16/32 Gb FC connections. The ThinkSystem DE4000H Storage Array scales up to 192 drives with the attachment of Lenovo ThinkSystem DE120S 2U12, DE240S 2U24 SFF, and DE600S 4U60 LFF Expansion Enclosures. It also offers flexible drive configurations with the choice of 2.5-inch (SFF) and 3.5-inch (LFF) form factors, 10 K rpm SAS and 7.2 K rpm NL SAS hard disk drives (HDDs), and SAS solid-state drives (SSDs).
Product Type	DAS/SAN Storage System

Storage

Number of Hard Drives Supported	12
Number of Hard Drives Installed	0
Number of Solid State Drive Supported	12
Number of Solid State Drive Installed	0
SSD Cache Capacity	8 GB

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	12
Number of 3.5" Bays	12

Controllers

Number of Controllers	2
Controller Type	12Gb/s SAS
RAID Supported	Yes
RAID Levels	0, 1, 3, 5, 6, 10

Interfaces/Ports

Host Interface	12Gb/s SAS
Number of SAS Ports (External)	4
Total Number of USB Ports	2
Fibre Channel	Yes

Management & Protocols

Protocols

FCP
SSH
SMI-S
SNMP
SSL
LDAP

Power Description

Number of Power Supplies Installed	2
Plug/Connector Type	C13 to IEC 320-C14
Maximum Power Supply Wattage	913 W
Redundant Power Supply	Yes

Physical Characteristics

Height	3.3"
Width	17.6"
Depth	19"
Form Factor	Rack-mountable
Rack Height	2U

Miscellaneous

Package Contents	ThinkSystem DE4000H FC Hybrid Flash Array LFF Rack Mount Kit 2 m USB Cable (USB Type A to Micro-USB) Quick Installation Guide Electronic Publications Flyer 2 x Power Cables
Environmentally Friendly	Yes

Warranty

Limited Warranty	3 Year
Additional Warranty Information	Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD) parts delivered.
