CRUCIAL 2GB DDR3-1600 UDIMM 1RX8

Name: CRUCIAL 2GB DDR3-1600 UDIMM 1RX8
Brand: MICRON - SOURCING
SKU: VK1154
Price: 60.03 USD
Availability: InStock

MICRON - SOURCING

PCN#

VK1154

MFG#

CT25664BA160B

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$60.03

Extended & Accidental Damage Product Replacement Plan Available Details

2-Year $23.99

1-Year $17.99

Estimated Shipment:

Product Highlights:

For Desktop PC
2 GB (1 x 2GB)
DDR3
1600/PC3
12800 DDR3 SDRAM
1600 MHz
CL11
1.50 V
Non
ECC
Unbuffered
240
pin
DIMM
Lifetime Warranty

Product Condition: New and Factory Fresh

Limited WarrantyLifetime

Shipping Weight: 1 lbs.

Micron 2GB (1 x 2 GB) DDR3 SDRAM Memory Module

Overview

Tech Specs

Specifications

Manufacturer	Micron Technology, Inc
Manufacturer Part Number	CT25664BA160B
Manufacturer Website Address	http://www.micron.com
Brand Name	Micron
Product Name	2GB (1 x 2 GB) DDR3 SDRAM Memory Module
Marketing Information	Crucial 240-pin DIMMs are used in DDR3 memory for desktop computers. DDR3 is the latest generation of memory with an improved architecture that allows it to transmit data more quickly. A dual inline memory module (DIMM) consists of a number of memory components (usually black) that are attached to a printed circuit board (usually green). The gold pins on the bottom of the DIMM provide a connection between the module and a socket on a larger printed circuit board. The pins on the front and back of a DIMM are not connected to each other. Each 240-pin DIMM provides a 64-bit data path (72-bit for ECC or registered or Fully Buffered modules). (The Ballistix™ and Ballistix Tracer™ high-performance memory do not come in 72-bit or registered modules.) Standard DDR3 240-pin DIMMs are currently available in PC3-8500 (DDR3 1066MHz) and PC3-10600 (DDR3 1333MHz) speeds. Additional speeds will be added as the technology becomes available. To use DDR3 memory, your system motherboard must have 240-pin DIMM slots and a DDR3-enabled chipset. This is because a DDR3 SDRAM DIMM will not fit into a standard DDR2 DIMM socket or a DDR DIMM socket. The number of black components on a 240-pin DIMM can vary, but it always has 120 pins on the front and 120 pins on the back, for a total of 240. 240-pin DIMMs are approximately 5.25 inches long and 1.18 inches high, though the heights can vary. While 240-pin DDR3 DIMMS, 240-pin DDR2 DIMMs, 184-pin DDR DIMMs, and 168-pin DIMMs are approximately the same size, 240-pin DIMMs and 184-pin DIMMs have only one notch within the row of pins.
Product Type	RAM Module

Technical Information

Memory Size	2 GB
Memory Technology	DDR3 SDRAM
Memory Voltage	1.50 V
Number of Modules	1 x 2GB
Memory Speed	1600 MHz
Memory Standard	DDR3-1600/PC3-12800
Error Checking	Non-ECC
Signal Processing	Unbuffered
CAS Latency	CL11
Device Supported	Desktop PC

Physical Characteristics

Number of Pins	240-pin
Form Factor	DIMM
Width	1.2"
Length	5.3"

Miscellaneous

Compatibility	ASRock Motherboard P55 Extreme EVGA EVGA Motherboard X58 SLI (132-BL-E758-A1) XFX Motherboard MB-X58I-CH19 MSI (Micro Star) Motherboard MS-7522 (X58 Pro) Elite Group (ECS) Motherboard IC780M-A2 (V1.0A)
Environmentally Friendly	Yes
Environmental Compliance	Restriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE)

Warranty

Limited Warranty

Lifetime
