BOSCH SECURITY ACCESS CONTROL SYSTEM BLACK

Name: BOSCH SECURITY ACCESS CONTROL SYSTEM BLACK
Brand: OEM SOURCING
SKU: Z62493
Price: 390.72 USD
Availability: OutOfStock

OEM SOURCING

PCN#

Z62493

MFG#

B4512

Estimated Shipment:

Product Highlights: No Description Found

Product Condition: New and Factory Fresh

Shipping Weight: 1 lbs.

Bosch B4512 Fire Alarm Control Panel

Tech Specs

Specifications

Manufacturer	The Bosch Group
Manufacturer Part Number	B4512
Manufacturer Website Address	http://www.bosch.com
Brand Name	Bosch
Product Series	B
Product Model	B4512
Product Name	B4512 Fire Alarm Control Panel
Marketing Information	Supports up to 28 points using a combination of hardwired or wireless points for installation flexibility and 2 areas with perimeter and interior control On-board Ethernet port for Conettix IP alarm communication and remote programming, compatible with modern IP networks including IPv6/IPv4, Auto-IP and Universal Plug and Play Installer-friendly features including on-board USB for easy on-site RPS programming, plus plug-in PSTN and Cellular co The B4512 Control Panel integrates intrusion and residential fire, providing one simple user interface for both systems. The B4512 provides up to 28 individually identified points that can be split into 2 areas. The control panel includes a built-in Ethernet port for IP network communications, and is compatible with modules that send events to selected public switched telephone network (PSTN), IP network, or cellular network destinations through four programmable route groups. With the B4512, you can monitor doors, windows, and motion within areas like showrooms or those that hold inventory. Each user can have a personalized passcode, a wireless keyfob, and a credential to control the system.
Packaged Quantity	1
Product Type	Fire Alarm Control Panel

Technical Information

Network & Communication

Ethernet

Yes

Power Description

Input Voltage

12 V DC

Miscellaneous

Package Contents	B4512 Fire Alarm Control Panel 1 x Literature Pack UL Installation Instructions Owner's Manual Release Notes SIA Quick Reference Guide 1 x Literature CD Containing Product Literature
Additional Information	Relative humidity 5% to 93% at +90? (+32?), non-condensing Temperature (operating) +32°F to +122°F (0°C to +49°C) Areas 2 Custom functions 2 Events Up to 127 Passcode users 32, plus 1 Installer passcode Points 28 (8 on-board, up to 20 off-board) Programmable outputs 27 (3 on-board, up to 24 off-board) RF points 20 SKEDs 5 Current draw (maximum) Idle 125 mA; Alarm 155 mA Output (alarm) 1.3 A at 12 VDC Output (auxiliary, continuous power, and switched auxiliary combined): 800 mA at 12 VDC nominal
Certifications & Standards	UL ULC CSFM
Environmentally Friendly	Yes
