SINGLE PAIR ETHERNET CONVERTER 10BASE-T1L APL CLASS A 3PIN SPE DC

The OmniConverter 10T/APS Single Pair Ethernet converters are 10BASE-T1L products that convert 10BASE-T Ethernet to 10BASE-T1L Ethernet. They are designed for digital instrumentation solutions used for industrial control processes. They utilize single-pair Ethernet cabling (SPE) to extend the Ethernet link distance up to 200 or 1000 meters depending on the model number.

The 10T/APS converters feature one 10BASE-T1L 3-pin terminal or IEC 63171-2 port and one 10BASE-T RJ-45 port supporting 10Mbps full-duplex data rates.

Omnitron 10T/APS converters are interoperable with Ethernet-APL Class A, C, 3 and 4 edge/field devices and act as a Power Source capable of delivering up to 56 watts, depending on the model number. The 10T/APS models 2022 and 2024 support a fixed voltage of 1.0 V peak-to-peak to the field device. The 10T/APS models 2025 and 2027 automatic detection of link segment type and apply either 1.0 V or 2.4 V peak-to-peak to the field device.

The 10T/APS converters are interoperable with Ethernet-APL Field Devices using either Ethernet-APL Spur Segments or Ethernet-APL Trunk Segments. A Spur segment has a maximum distance of 200 meters and data signal amplitude of 1.0 volt peak-to-peak. A Trunk segment has a maximum distance of 1000 meters and data signal amplitude of 2.4 volts peak-to-peak.

They are available as standalone units with integrated mounting brackets. They can be DIN-rail mounted using the optional DIN-rail mounting clip kit (8252-0). Models come with a 2-pin DC power terminal connector.

• 10Base-T
• 10Base-T1L

• OmniConverter 10T/APS 10BASE-T to 10BASE-T1L Media Converter RJ-45 T1L SPE 3-Pin Terminal
• User Manual

• UL 62368-1
• UL 60950-1
• IEC 62368-1
• IEC 60950-1
• CUL CSA C22.2 No. 60950-1
• EN 60950-1:2006
• CE Mark
• UKCA
• FCC 47CFR, Part 15 Class A
• AS/NZS 3548, AS/NZS 4417.1 and AS/NZS 4417.2
• ICES-003 Issue 3
• EN 55032/CISPR 22 and EN55035
• EN61000-3-2
• VCCI V3/2001.04 (CISPR 22A:1997, Class A)
• IEC/EN61000-4-2
• IEC/EN61000-4-3
• IEC/EN61000-4-4
• IEC/EN61000-4-5
• IEC/EN61000-4-6
• IEC/EN61000-4-8
• IEC/EN61000-4-11

• Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
• Restriction of Hazardous Substances (RoHS)
• Waste Electrical and Electronic Equipment Directive (WEEE)
