OWC 14-PORT THUNDERBOLT DOCK THUNDERBOLT 40GB/S CONNECTIVITY SOLUTION FOR MAC/PC

Name: OWC 14-PORT THUNDERBOLT DOCK THUNDERBOLT 40GB/S CONNECTIVITY SOLUTION FOR MAC/PC
Brand: OWC
SKU: 8404BS
Price: 190.61 USD
Availability: InStock

OWC

PCN#

8404BS

MFG#

OWCTB3DK14PSG

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$190.61

Extended & Accidental Damage Protection Plans Available Details

2-Year $25.99

3-Year $36.99

Free Shipping

Estimated Shipment:

Product Highlights:

Thunderbolt 3 (40Gb/s)
1x Thunderbolt Host Port With Up To 85W PD
1x Thunderbolt
1x USB
C (10Gb/s)
5x USB
A (5Gb/s)
1x Mini DisplayPort
1x 1GbE
1x SD Reader
1x microSD Reader
1x S/PDIF Digital Audio
1x 3.5mm Audio In/Out
2 Year Limited Warranty

Product Condition: New and Factory Fresh

Limited WarrantyKensington Security SlotNoCompatibilityThunderbolt 3 equipped Windows PC or MacBrand CompatibilityAppleEnvironmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)Restriction of Hazardous Substances (RoHS)Warranty

Shipping Weight: 4 lbs.

OWC 14-Port Thunderbolt Dock for Mac/PC with 85W Power - Thunderbolt 3 - Ethernet - Reader - USB - Audio

Overview

Tech Specs

Specifications

Manufacturer	Other World Computing
Manufacturer Part Number	OWCTB3DK14PSG
Manufacturer Website Address	https://www.owc.com/
Brand Name	OWC
Product Name	14-Port Thunderbolt Dock
Marketing Information	One Cable. Connectivity for Your World. Through a single cable, the 14-Port Thunderbolt Dock brings an unprecedented combination of ports, convenience and power to your Thunderbolt equipped PC or Mac. Bring functionality back to your notebook. Quickly access all of the displays and peripherals at your desk while minimizing desk clutter. Charge your computer and all of your mobile devices simultaneously. Connect and make any shared workspace feel like home. Welcome to your new world of connectivity. Connect. Work. Disconnect. Go. The days of only working at your desk are gone. We're always on the move bouncing between our desks, meetings, and couches - often in a hurry. With a single connection to your notebook computer, the 14-Port Thunderbolt Dock makes coming back to your desk to work and leaving your desk to run to a meeting, a much quicker endeavor. The Right Ports. Right Where You Need Them. Our engineers evaluated thousands of possibilities in discovering the optimal port configuration for nearly any environment. With each port thoughtfully placed, the 14-Port Thunderbolt Dock delivers convenience while keeping desktops clutter-free. The docking station's front is designed for the easy connection of your portable devices, headphones and media cards, while the rear features a multitude of ports for your static devices so cables stay out of sight. Thunderbolt Power: Harness the power of Thunderbolt to achieve the highest-speed and most connection options. The dock's main Thunderbolt port provides up to 85W of power to your notebook computer, while the secondary Thunderbolt port provides Thunderbolt daisy-chaining, USB, and display support. Card Readers: Harness the power of Thunderbolt to achieve the highest-speed and most connection options. The dock's main Thunderbolt port provides up to 85W of power to your notebook computer, while the secondary Thunderbolt port provides Thunderbolt daisy-chaining, USB, and display support. USB connections that matter: Move into the future without leaving the past behind with two USB-C (10Gb/s) ports as well as five USB-A (5Gb/s) ports. Connect printers, storage and keyboards via USB-A, or the latest mobile devices and drives via USB-C. Plus, charge-up faster with high-powered ports. Music to your ears, and everyone else's: Full-range, wired headphones are key to audio production. Cruise through your music timelines, compose your next track, jam on your next beat, create some vocals, or even a podcast with the convenient front-facing in/out 3.5mm audio jack for headphones, mics, audio sources and more. Multiple displays, multiple types: Screen real estate is a must. One display is no longer enough for office workers, gamers or students, let alone creative professionals. With display support via Mini DisplayPort and Thunderbolt (USB-C), triple your screen real estate with two displays with up to 4K resolution or a single 5K display. Gigabit Ethernet - wired for speed, security: Access high-speed, reliable and secure wired networks with fast data transfers and the peace-of-mind that comes with hardwired connection. Experience fast 1000Mb/s bandwidth versus slower 600Mb/s 802.11n or 48Mb/s 802.11g wireless standards. S/PDIF Digital Audio Output Port: Connect your pristine digital audio source into your audio workflow, consoles, home audio receiver / amplifier, and more.
Packaged Quantity	1
Product Type	Docking Station

Technical Information

Connectivity Technology	Wired
Charging Capability	Yes
Device Supported	Notebook
Cable Length	2.30 ft
Memory Card Reader	Yes
Memory Card Supported	SD microSD
Number of Displays Supported	2
Screen Mode Supported	5K @ 60Hz 4K @ 60Hz
Supported Resolutions	3840 x 2160 5120 x 2880
Maximum Data Transfer Rate	5 GB/s

Network & Communication

Ethernet Technology

Gigabit Ethernet

Interfaces/Ports

Host Interface	Thunderbolt 3
Total Number of USB Ports	6
USB Type-A	Yes
Number of USB 3.2 Gen 1 Type-A Ports	5
Number of USB Type-A Ports	5
USB Type-C	Yes
USB Type-C Detail	1 x USB 3.2 Gen 2 Type-C Port up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible
Number of USB Type-C Ports	1
Network (RJ-45)	Yes
Number of RJ-45 Ports	1
S/PDIF Out	Yes
Mini DisplayPort	Yes
Number of Mini DisplayPort	1
Headphone/Microphone Combo Port	Yes
Thunderbolt	Yes
Number of Thunderbolt 3 Ports	1
USB Power Delivery	85W

Software

Operating System Supported

Mac OS X 10.12 Sierra
Mac OS X 10.13 High Sierra
Mac OS X 10.14 Mojave
Mac OS X 10.15 Catalina
Mac OS X 11.0 Big Sur
Mac OS X 12.0 Monterey
Mac OS X 13.0 Ventura
Mac OS X 14.x Sonoma
macOS Sequoia 15
Windows Server 2016
Windows 10
Windows 11

Power Description

Input Voltage Detail	120 V AC 230 V AC
Frequency	50 Hz 60 Hz
Maximum Power Supply Wattage	180 W
Power Source Type	Power Adapter

Physical Characteristics

Color Family	Dual Color
Product Color	Black Space Gray
Height	0.98"
Width	9.06"
Length	3.5"
Weight (Approximate)	1.10 lb

Miscellaneous

Package Contents	14-Port Thunderbolt Dock 1 x 0.7M (28") Thunderbolt Cable 1 x External Power Supply and Power Cable 1 x Quick Start Guide for OWC 14-Port Thunderbolt Dock 1 x User Guide for OWC 14-Port Thunderbolt Dock 1 x OWC Dock Ejector for Mac and Windows (software download) 1 x User Guide for OWC Dock Ejector 2 Year OWC Limited Warranty
Kensington Security Slot	No
Compatibility	Thunderbolt 3 equipped Windows PC or Mac
Brand Compatibility	Apple
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

2 Year
