G6 MSPO PDU 415V 30AMP 48-C13 N EMAL22-30P-3M TF BLK PK1

Name: G6 MSPO PDU 415V 30AMP 48-C13 N EMAL22-30P-3M TF BLK PK1
Brand: PANDUIT
SKU: XS7115
Price: 4670.12 USD
Availability: InStock

PANDUIT

PCN#

XS7115

MFG#

P48G04G

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Authorized Dealer

$4,670.12

Extended & Accidental Damage Protection Plans Available Details

2-Year $331.99

3-Year $446.99

Free Shipping

Estimated Shipment:

Product Highlights:

Monitored, Switched
NEMA L22
30P
48 x IEC 60320 C13
415 V
Network (RJ
45)
Vertical

Product Condition: New and Factory Fresh

Shipping Weight: 10 lbs.

Panduit G6 MSPO PDU, 415V, 30 AMP, (48)C13, NEMA L22-30P, NCNR

Overview

Tech Specs

Specifications

Manufacturer	PANDUIT CORP
Manufacturer Part Number	P48G04G
Manufacturer Website Address	http://www.panduit.com
Brand Name	Panduit
Product Series	G6
Product Name	G6 MSPO PDU, 415V, 30 AMP, (48)C13, NEMA L22-30P, NCNR
Product Type	PDU

Technical Information

PDU Type	Monitored Switched
Phase	Three Phase
Plug/Connector Type	NEMA L22-30P
Receptacle Type	IEC 60320 C13
Receptacle Detail	48 x IEC 60320 C13

Power Description

Input Voltage	415 V
Output Voltage	240 V AC
Power Rating (VA)	17.30 kVA
Input Current	30 A

Interfaces/Ports

Network (RJ-45)	Yes
USB	Yes

Physical Characteristics

Color Family	Black
Product Color	Black
Product Material	Metal
Mounting Orientation	Vertical
Height	74"
Width	3.3"
Depth	2.1"

Environmental Conditions

Minimum Operating Temperature	50°F (10°C)
Maximum Operating Temperature	140°F (60°C)
Minimum Storage Temperature	24.8°F (-4°C)
Maximum Storage Temperature	284°F (140°C)

Miscellaneous

Package Contents	G6 MSPO PDU, 415V, 30 AMP, (48)C13, NEMA L22-30P, NCNR Mounting Hardware
Additional Information	Use display to set IP address, update firmware, quick configure, rotate display, balance loads across phases, view alarms, read current, voltage, power and energy on the device Cascade up to 32 PDUs
Certifications & Standards	UL 62368-1 IEC 62368-1 (EMEA) FCC Pat 15 Class A (USA) RETIE (Colombia)
Country of Origin	India
Environmentally Friendly	Yes
Environmental Compliance	Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Restriction of Hazardous Substances (RoHS)
