G6 MS PDU 32AMP(38)C13(6)C19 IE NT BRACKET 600MM BLACK

Name: G6 MS PDU 32AMP(38)C13(6)C19 IE NT BRACKET 600MM BLACK
Brand: PANDUIT POWER
SKU: Z76376
Price: 2758.84 USD
Availability: InStock

PANDUIT POWER

PCN#

Z76376

MFG#

P44E07G

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$2,758.84

Extended & Accidental Damage Protection Plans Available Details

2-Year $197.99

3-Year $263.99

Free Shipping

Estimated Shipment:

Product Highlights:

Monitored
IEC 60309 2P+E 6h 32A (IP44)
38 x IEC 60320 C13, 6 x IEC 60320 C19
208 V AC
Network (RJ
45)
10 ft Cord Length
0U
Vertical
Rack
mountable
Rack, Full

Product Condition: New and Factory Fresh

Limited Warranty5 YearAdditional Warranty InformationThree-year default warranty plus two free years upon online registration

Shipping Weight: 20 lbs.

Panduit G6 MS PDU, 32AMP, (38)C13, (6)C19, IEC 60309 2P+E 6h

Overview

Tech Specs

Specifications

Manufacturer	PANDUIT CORP
Manufacturer Part Number	P44E07G
Manufacturer Website Address	http://www.panduit.com
Brand Name	Panduit
Product Series	G6
Product Name	G6 MS PDU, 32AMP, (38)C13, (6)C19, IEC 60309 2P+E 6h
Marketing Information	The Panduit G6 Monitored Switched PDU features (38) C13 and (6) C19 outlets. It is a 32 amp, 230 V, single phase PDU with an IEC 60309 2P+E 6h 32A (IP44) input plug and a 10 foot (3m) power cord. The PDU is black.
Packaged Quantity	1 Piece
Product Type	PDU

Technical Information

PDU Type	Monitored
Phase	Single Phase
Plug/Connector Type	IEC 60309 2P+E 6h 32A (IP44)
Receptacle Type	IEC 60320 C13 IEC 60320 C19
Receptacle Detail	38 x IEC 60320 C13 6 x IEC 60320 C19
Features	LCD Display
Load Capacity (VA)	7400 W

Power Description

Input Voltage	208 V AC
Input Voltage Range	100 V AC - 240 V AC
Output Voltage	208 V AC
Output Voltage Range	120 V AC - 240 V AC
Input Current	32 A
Input Frequency	60 Hz
Circuit Breaker	Yes
Number of Circuit Breakers	2
Voltage Measurement Accuracy	±1%
Power Measurement Accuracy	±1%
Current Measurement Accuracy	±1%

Management

SNMP

Interfaces/Ports

Network (RJ-45)

Yes

Physical Characteristics

Color Family	Black
Product Color	Black
Product Material	Metal
Mounting Orientation	Vertical
Mount Type	Rack-mountable
Form Factor	Rack Full
Rack Height	0U
Cord Length	10 ft
Height	69"
Width	2"
Depth	2.1"

Environmental Conditions

Minimum Operating Temperature	50°F (10°C)
Maximum Operating Temperature	140°F (60°C)
Minimum Storage Temperature	-4°F (-20°C)
Maximum Storage Temperature	140°F (60°C)

Miscellaneous

Package Contents	G6 MS PDU, 32AMP, (38)C13, (6)C19, IEC 60309 2P+E 6h 1 x Mounting Hardware Kit
Application/Usage	IT Equipment Server Rack/Cabinet Data Center
Certifications & Standards	UL 62368-1 FCC Pat 15 Class A (USA) NOM (Mexico) RETIE (Colombia)
Country of Origin	India
Environmental Compliance	Restriction of Hazardous Substances (RoHS) Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
UL Listed	Yes

Warranty

Limited Warranty	5 Year
Additional Warranty Information	Three-year default warranty plus two free years upon online registration
