165IN LD-AF SERIES ALL-IN-ONE FHD FULL HD (1920X1080) 165IN

Name: 165IN LD-AF SERIES ALL-IN-ONE FHD FULL HD (1920X1080) 165IN
Brand: SHARP
SKU: UJ3100
Price: 33122.31 USD
Availability: InStock

SHARP

PCN#

UJ3100

MFG#

LD-A1651F

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$33,122.31

Estimated Shipment:

Product Highlights:

13.75 ft LCD
ARM Cortex A55 1.50 GHz
4 GB
1920 x 1080
16:9
Direct View LED
500 Nit
1080p
Speakers
HDMI
USB
SerialEthernet
Android 13

Product Condition: New and Factory Fresh

Limited Warranty2 Year

Shipping Weight: 732 lbs.

Sharp 165" LD-AF Series All-in-one FHD LED

Overview

Tech Specs

Specifications

Manufacturer	Sharp Electronics
Manufacturer Part Number	LD-A1651F
Manufacturer Website Address	http://www.sharpusa.com
Brand Name	Sharp
Product Series	LD-AF
Product Model	LD-A1651F
Product Name	165" LD-AF Series All-in-one FHD LED
Marketing Information	Sharp's new LD-AF Series of direct view LED displays offer a streamlined, user-friendly solution that differs from standard LED walls. Unlike traditional direct view LED displays, which often require additional components like external controllers or speakers, Sharp's LD-AF Series features built-in speakers, remote control functionality, and an intuitive interface for easy setup and operation. Designed for simplicity and convenience, these displays provide a unified user experience across Sharp's line of system-on-chip (SoC) displays, and a streamlined installation process. Available in 138" and 165" diagonal sizes, they deliver Full HD (1920x1080) imagery, making them perfect for environments like conference rooms and meeting spaces that need a high-quality, hassle-free display. Full HD (1920x1080) native resolutionwith a 165" class diagonal for crystal clear and immersive imagery Quick and easy installation processwith a single power cable and a hassle-free installation process, the Sharp LD-AF Series can be implemented in as little as two hours Powerful System-on-Chip for versatile functionalitypowered by Android 13 with a high-end integrated media player, as well as support for third-party applications (APKs) as needed Integrated USB-C connectionthat not only allows for DP-Alt mode, but also upstream cababilities for controlling peripherals through the separate USB-A downstream connection NaViSet Administratoris Sharp's proprietary software solution that greatly eases administration and management of larger disply device installations. Control your entire Sharp display ecosystem through this optional software Fully compatiblewith Crestron Connected software as well as Crestron XiO Cloud Service
Product Type	Digital Signage Display

Technical Information

Speaker Power	36 W
Ingress Protection (IP) Rating	IP20

Processor & Chipset

Processor Manufacturer	ARM
Processor Type	Cortex A55
Processor Speed	1.50 GHz
Processor Core	Quad-core (4 Core)

Memory

Standard Memory

4 GB

Display & Graphics

Number of Screens	1
Viewable Screen Size	13.75 ft
Screen Size Class	13.75 ft
Display Screen Type	LCD
Display Resolution	1920 x 1080
Pixel Pitch	74.8 mil
Aspect Ratio	16:9
Horizontal Viewing Angle	80°
Vertical Viewing Angle	70°
Backlight Technology	Direct View LED
Orientation	Landscape
Module Resolution	320 x 180
Maximum LED Life	11.4 Year
Pixel Configuration	3-in-1 SMD

Audio

Number of Speakers	2
Speakers	Yes

Video

Scan Format	1080p
Standard Refresh Rate	3.84 kHz
Dynamic Contrast Ratio	6,500:1
Color Depth	16-bit
Brightness	500 Nit

Network & Communication

Ethernet

Yes

Interfaces/Ports

USB	Yes
HDMI	Yes
Serial	Yes
Number of USB 2.0 Ports	1
Number of USB 3.0 Ports	2
Number of HDMI Inputs	3
USB Type-C	Yes
RS-232C Input	Yes
Number of HDMI 2.0 Ports	3

Software

Operating System

Android 13

Power Description

Power Consumption

2150 W

Environmental Conditions

Minimum Operating Temperature	32°F (0°C)
Maximum Operating Temperature	104°F (40°C)
Minimum Storage Temperature	-4°F (-20°C)
Maximum Storage Temperature	140°F (60°C)
Minimum Operating Humidity	10%
Maximum Operating Humidity	80%
Minimum Storage Humidity	10%
Maximum Storage Humidity	80%

Physical Characteristics

Mount Type	Wall Mountable
Height	85.7"
Width	12.1 ft
Depth	3"
Weight (Approximate)	459 lb

Miscellaneous

Package Contents	165" LD-AF Series All-in-one FHD LED Remote control Wall mount
Indoor/Outdoor	Indoor
Application/Usage	Conference Room Meeting Room
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

2 Year
