55IN LED LCD SPVA 25 HAZE 700 CD/M2 ULTRA NARROW BEZEL (0.88MM)

Name: 55IN LED LCD SPVA 25 HAZE 700 CD/M2 ULTRA NARROW BEZEL (0.88MM)
Brand: SHARP
SKU: Z32455
Price: 5640.43 USD
Availability: InStock

SHARP

PCN#

Z32455

MFG#

PN-UN553S

Skip to the end of the images gallery

Skip to the beginning of the images gallery

$5,640.43

Extended & Accidental Damage Protection Plans Available Details

3-Year $471.99

2-Year $354.99

Estimated Shipment:

Product Highlights:

55" LCD
Super In
plane Switching (S
IPS) Technology
High Dynamic Range (HDR)
24 Hours/7 Days Operation
1920 x 1080
16:9
8 ms
Direct LED
700 Nit
1080p
HDMI
USB
DVI
SerialEthernet

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 89 lbs.

Sharp 55" Ultra-Narrow Bezel Professional-Grade Display

Overview

Tech Specs

Specifications

Manufacturer	Sharp Electronics
Manufacturer Part Number	PN-UN553S
Manufacturer Website Address	http://www.sharpusa.com
Brand Name	Sharp
Product Model	PN-UN553S
Product Name	55" Ultra-Narrow Bezel Professional-Grade Display
Marketing Information	55" Ultra-Narrow Bezel Professional-Grade Display Sharp's 55" PN-UN553S sets the standard for quality color reproduction in video wall environments. Direct LED backlighting and factory calibration for brightness intensity, gamma, uniformity, white point and RGB allows for ideal panel settings and an easy out-of-the-box experience. Brand new panel technology minimizes the bezel gap of this display, allowing for a < 1.0mm distance between adjacent displays with a 0.44mm even and near bezel-less design per unit. This display is integrated with the proprietary SpectraView Engine, which not only allows for ultimate color control but also allows for increased color calibration capabilities including white copy, self calibration to an external sensor and manual CIE chromaticity adjustment for maximum control when color matters most. This display also includes both a DisplayPort and an HDMI Out connections for daisy chaining signals up to 4K UHD. This new generation of display also received a full chassis upgrade with faster processing times, evolved daisy chain performance, and new TileMatrixing capabilities. Features SpectraView Engine exclusive color processing allows for an unparalleled level of color control, uniformity, accuracy and stability Near Bezel-less panel technology allows for an even 0.44mm design, allowing for the distance between adjacent displays to be <1.0mm 700cd/m2 panel brightness combined with full HD resolution will capture the attention of the audience Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allow for 24/7 operation HDMI and DisplayPort daisy chain capabilities can support up to 4K UHD resolution TileCut function added to the TileMatrix functionality for ultimate adjustment of the imagery in the wall Uniformity calibration of each display for gamma, intensity and RGB for consistency from display to display
Product Type	Digital Signage Display

Technical Information

Video Wall Compatible	Yes
Bezel Width (Bottom)	17.3 mil
Bezel Width (Top)	17.3 mil
Bezel Width (Left)	17.3 mil
Bezel Width (Right)	17.3 mil
Panel Technology	Super In-plane Switching (S-IPS) Technology
Operation Hours	24 Hours/7 Days

Display & Graphics

Number of Screens	1
Viewable Screen Size	55"
Screen Size Class	55"
Display Screen Type	LCD
Display Resolution	1920 x 1080
High Dynamic Range (HDR)	Yes
Response Time	8 ms
Pixel Pitch	24.8 mil
Aspect Ratio	16:9
Backlight Technology	Direct LED
Orientation	Landscape/Portrait

Video

Scan Format	1080p
Native Contrast Ratio	1,100:1
Brightness	700 Nit

Network & Communication

Ethernet

Yes

Interfaces/Ports

USB	Yes
DVI	Yes
HDMI	Yes
DisplayPort	Yes
Serial	Yes
Number of HDMI Inputs	2
Number of DisplayPorts	2
DisplayPort Output	Yes
RS-232C Input	Yes
Number of HDMI 2.0 Ports	2
Number of DisplayPort 1.2 Ports	2
DVI-D In	Yes

Power Description

Input Voltage

120 V AC
230 V AC

Environmental Conditions

Minimum Operating Temperature	41°F (5°C)
Maximum Operating Temperature	104°F (40°C)
Minimum Storage Temperature	-4°F (-20°C)
Maximum Storage Temperature	140°F (60°C)
Minimum Operating Humidity	20%
Maximum Operating Humidity	80%
Minimum Storage Humidity	10%
Maximum Storage Humidity	90%

Physical Characteristics

VESA Mount Standard	400 x 400
Height	26.8"
Width	47.7"
Depth	3.9"
Weight (Approximate)	61.95 lb

Miscellaneous

Package Contents	55" Ultra-Narrow Bezel Professional-Grade Display 2.0m DisplayPort cable 2.0m HDMI cable 3.0m Power cord Clamp for Power Cable Contents Sheet LAN cable SD Card Cover Setup Manual
Application/Usage	Professional Audio/Video Industrial

Warranty

Limited Warranty

3 Year
