Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support - TAA Compliant

Name: Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support - TAA Compliant
Brand: SHUTTLE COMPUTER
SKU: 11NG09
Price: 395.05 USD
Availability: InStock

SHUTTLE COMPUTER

PCN#

11NG09

MFG#

DH470TPM

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

Intel H470 Chip
64 GB DDR4 SDRAM DDR4
2933/PC4
23466 Maximum RAM Support
2 Total Memory Slots
Serial ATA/600 Controller
Intel HD Graphics Graphic(s)
1 2.5" Bay(s)
Network (RJ
45)
2 M.2 Interface(s)
1 SATA Interface(s)
Processor Support (Core i9, Core i7, Core i5, Core i3, Pentium Gold, Celeron)
Gigabit Ethernet
Windows 10 x64, Linux Supported Operating System
3 USB 3.2 Gen 1 Port(s)
90 W
3 Year

Product Condition: New and Factory Fresh

Limited Warranty3 Year

Shipping Weight: 6 lbs.

Shuttle XPC slim DH470 Barebone System - Slim PC - Socket LGA-1200 - 1 x Processor Support - TAA Compliant

Overview

Tech Specs

Specifications

Manufacturer	Shuttle, Inc
Manufacturer Part Number	DH470TPM
Manufacturer Website Address	http://www.us.shuttle.com
Brand Name	Shuttle
Product Line	XPC slim
Product Model	DH470
Product Name	XPC slim DH470 Barebone System
Marketing Information	ROBUST 1.3-LITRE SLIMPC SUPPORTS INTEL "COMET LAKE-S" 10-CORE PROCESSORS AND THREE UHD DISPLAYS The Shuttle XPC slim Barebone DH470 with H470 chipset houses the performance of Intel's 10th generation Core desktop processors (codenamed Comet Lake-S) for socket LGA1200 in a compact 1.3-litre format. The DH470 allows for three Ultra HD displays to be operated at the same time via HDMI 2.0a and 2x DisplayPort. It also offers Dual Intel LAN, four USB 3.2 Gen 2 and COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
Product Type	Barebone System

Processor

Number of Processors Supported	1
Processor Socket	Socket LGA-1200
Processor Supported	Core i9 Core i7 Core i5 Core i3 Pentium Gold Celeron
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	H470

Memory

Maximum Memory Supported	64 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-2933/PC4-23466
Number of Total Memory Slots	2

Storage

Supported Storage Drive Interfaces	Serial ATA III PCI Express NVMe 4.0 PCI Express 3.0 x4
Supported Storage Drive Types	SSD HDD

Controllers

Controller Type

Serial ATA/600

Display & Graphics

Graphics Controller Manufacturer	Intel
Graphics Controller Model	HD Graphics
Graphics Memory Technology	DDR4 SDRAM
Graphics Memory Accessibility	Shared

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	1
Number of Internal 2.5" Bays	1
Number of M.2 Interfaces	2

Interfaces/Ports

HDMI (Rear)	Yes
Total Number of USB Ports	8
Number of USB 3.2 Gen 1 Ports	3
Number of USB 3.2 Gen 2 Ports	4
USB Type-C (Front)	Yes
USB Type-C Detail	1x Type-C
Network (RJ-45)	Yes
Number of SATA Interfaces	1

Operating System

Operating System Supported

Windows 10 x64
Linux

Power Description

Input Voltage	120 V AC 230 V AC
Maximum Power Supply Wattage	90 W
Frequency	50 Hz 60 Hz

Physical Characteristics

Product Color	Black
Form Factor	Slim PC
Height	1.7"
Width	6.5"
Depth	7.5"
Weight (Approximate)	2.87 lb

Miscellaneous

Package Contents	XPC slim DH470 Barebone System Multi-Language User Guide (EN, DE, FR, ES, JP, KR, SC, TC) VESA Mount for 75/100 mm Standard (two metal brackets) 4 x Screws M3 x 5 mm (screws together VESA mount and PC) 4 x Screws M4 x 10 mm (to affix VESA mount on the PC) 4 x Screws M3 x 4 mm (to mount a 2.5" storage device into the bay) 2 x Screws M3 x 5 mm (silver colour, to mount two M.2 cards) Driver DVD (Windows 64-bit) Serial ATA Cable for 2.5" Drive Including Power Cable External 90 W Power Adapter with Power Cord Protection Cap for CPU Socket (do not use if heatpipe or fan is mounted) Heatsink Compound
Energy Star	Yes
Environmentally Friendly	Yes
Energy Efficiency Compliance	Energy-related Products Directive (ErP)
Environmental Compliance	Restriction of Hazardous Substances (RoHS)
TAA Compliant	Yes

Warranty

Limited Warranty

3 Year
