Shuttle XPC slim XH510G2 Barebone System - Socket LGA-1200 - 1 x Processor Support

Name: Shuttle XPC slim XH510G2 Barebone System - Socket LGA-1200 - 1 x Processor Support
Brand: SHUTTLE COMPUTER
SKU: 10HV48
Price: 412.43 USD
Availability: InStock

SHUTTLE COMPUTER

PCN#

10HV48

MFG#

XH510G2

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Estimated Shipment:

Product Highlights:

Intel H510 Express Chip
64 GB DDR4 SDRAM DDR4
3200/PC4
25600 Maximum RAM Support
2 Total Memory Slots
Serial ATA/600 Controller
1 2.5" Bay(s)
Processor Support (Core i3, Core i5, Core i7, Core i9, Pentium Gold, Celeron)
Gigabit Ethernet
Windows 10 x64, Windows 11 x64, Linux Supported Operating System
4 USB 3.2 Gen 1 Port(s)
180 W

Product Condition: New and Factory Fresh

Shipping Weight: 8 lbs.

Shuttle XPC slim XH510G2 Barebone System - Socket LGA-1200 - 1 x Processor Support

Overview

Tech Specs

Specifications

Manufacturer	Shuttle, Inc
Manufacturer Part Number	XH510G2
Manufacturer Website Address	http://www.us.shuttle.com
Brand Name	Shuttle
Product Line	XPC slim
Product Model	XH510G2
Product Name	XPC slim XH510G2 Barebone System
Marketing Information	FLEXIBLE 4.7-LITRE PC WITH PCIE SLOT The Shuttle XPC slim Barebone XH510G2 is a 4.7-litre PC with two slots for PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.
Product Type	Barebone System

Processor

Number of Processors Supported	1
Processor Socket	Socket LGA-1200
Processor Supported	Core i3 Core i5 Core i7 Core i9 Pentium Gold Celeron
64-bit Processing	Yes

Chipset

Chipset Manufacturer	Intel
Chipset Model	H510 Express

Memory

Maximum Memory Supported	64 GB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Number of Total Memory Slots	2

Storage

Supported Storage Drive Interfaces

Serial ATA III

Controllers

Controller Type

Serial ATA/600

Network & Communication

Ethernet Technology

Gigabit Ethernet

I/O Expansions

Number of Total Expansion Bays	1
Number of Internal 2.5" Bays	1
Number of Total Expansion Slots	2
Number of PCI Express x16 Slots	1

Interfaces/Ports

HDMI (Rear)	Yes
Total Number of USB Ports	8
Number of USB 2.0 Ports	4
Number of USB 3.2 Gen 1 Ports	4

Operating System

Operating System Supported

Windows 10 x64
Windows 11 x64
Linux

Power Description

Input Voltage	120 V AC 230 V AC
Maximum Power Supply Wattage	180 W

Physical Characteristics

Height	3.7"
Width	7.9"
Depth	9.8"
Weight (Approximate)	6.57 lb

Miscellaneous

Application/Usage	Business
Energy Star	Yes
