OMADA PRO 4G+ AX3000 VPN RTR OMADA PRO 4G+ AX3000 VPN RTR

Get Instant 4G+ LTE Internet up to 300 MbpsInsert a Nano SIM card into the G36W-4G and get 4G+ Cat6 speeds up to 300 Mbps. G36W-4G provides a flexible and simple LTE option for remote areas with weak broadband signals. It always serves as a backup internet connection for your business.Featuring 4G+ Carrier Aggregation technology, the G36W-4G combines different carrier signals simultaneously to improve transmit efficiency. Faster broadband and reliable internet access are easy to get. Always-Online with AX3000 WiFi 6As an AX300 dual-band WiFi 6 router, the G36W-4G features dual-band signals with a 5G transfer rate of 2402 Mbps and a 2.4G transfer rate of 574 Mbps, reducing buffering and latency for smooth roaming. Intelligent Hardware DesignUp to six Gigabit ports provide high-speed wireless connectivity, meeting diverse networking needs.Two detachable LTE and three WiFi antennas deliver optimal coverage, improving the signal quality of 4G LTE and Wi-Fi respectively.Three real-time LTE signal indicators are displayed for optimal reception. Highly Secure VPNG36W-4G supports multiple VPN protocols, including SSL/ Wireguard/ OpenVPN/ GRE VPN/ IPSec/ PPTP/ L2TP/ L2TP over IPSec, helping users establish VPN connections more flexibly. One-click auto IPSec VPN greatly simplifies VPN configuration and facilitates network management and deployment while also securing and encrypting private site-to-site data communications traveling over the internet. Abundant Security FeaturesG36W-4G supports various security features. Advanced firewall policies protect your network's data and resources. Intrusion detection systems (IDS) monitor and analyze your network traffic for signs of intrusion. Intrusion prevention systems (IPS) support the protection of various threats such as botnets, malware, and terminal vulnerability attacks. IPS also features country-based blocking of malicious attacks, protecting your network with ease. DPI supports the detection and control of applications such as video software, games, and more. DoS Defense automatically detects and blocks Denial of Service (DoS) attacks such as TCP/UDP/ICMP Flooding, Ping of Death, and other related threats. IP-MAC binding reserves static IP assignments for clients to defend against ARP attacks and spoofing. More features, like advanced firewall policies, VLAN support, and one-click ALG activation, further improve network security. Internet Access Management StrategyStandardize users' online behavior and easily specify the internet access rights and strategies of employees via IP/MAC/URL Filtering and Access Control List (ACL). Captive portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests. Easy Management with the Omada AppUsers can configure G36W-4G in both the standalone and controller modes via the Omada app. Standalone management ensures maximum convenience. No need to set up additional controllers.Follow the configuration instructions on the app to get set up in minutes. Multi-function configuration is ready to go, including network status monitoring and client management, all from the comfort of a smartphone or tablet.Product TypeModem/Wireless RouterTechnical InformationWi-Fi GenerationWi-Fi 6Network BandDual BandMU-MIMO TechnologyYesAI-poweredYesMemory TechnologyDDR4 SDRAMStandard Memory512 MBWireless SpecificationsBroadband Transmission Technology

• Ethernet
• Cellular

Wireless LAN StandardIEEE 802.11axISM BandYesUNII BandYesISM Maximum Frequency2.40 GHzUNII Maximum Frequency5 GHzCellular Generation4G+Cellular Network Supported

• LTE 2100
• LTE 1800
• LTE 850
• LTE 2600
• LTE 900
• LTE 800
• LTE 700
• LTE 1450
• LTE 2300
• LTE 2500
• WCDMA 2100
• WCDMA 1800
• WCDMA 850
• WCDMA 900

Cellular Data Connectivity Technology

• HSPA+
• DC-HSDPA
• HSDPA
• HSUPA
• WCDMA
• LTE
• LTE Cat 6

Total Number of Antennas3Number of External Antennas3Total Wireless Transmission Speed300.25 MB/sEncryption Standard

• WPA-Personal
• WPA2-Personal
• WPA3-Personal
• WPA-ENT
• WPA2-ENT
• WPA3-ENT
• SHA-1
• SHA-256
• SHA-384
• SHA-512
• AES (256-bit)

Firewall TypeNATWi-Fi Mesh SystemYesWireless PerformanceAX3000Interfaces/PortsTotal Number of Network Ports5Number of Network (RJ-45) Ports4Number of Broadband (RJ-45) Ports1I/O ExpansionsTotal Number of Expansion Slots1Expansion Slot TypeSFP (mini-GBIC)Network & CommunicationEthernet TechnologyGigabit EthernetVPN SupportedYesNumber of SIM Card Supported1SIM Size SupportedNanoStorageFlash Memory Capacity128 MBPhysical CharacteristicsForm Factor

• Desktop
• Wall Mountable

Height1.4"Width8.9"Depth5.2"
